The Vecta+ Sensor Tap range are easy to install, as retrofit or new build installations. They help to improve hygiene and prevent the transfer of pathogens with no-touch controls. With an infrared tap, the water only runs while your hands are in range, so these taps reduce wasted water, increase efficiency, save energy and reduce costs, while maintaining reliability and high performance.
Made to high standards, with options for mains or battery power, out of the box as standard. Our range of infrared sensor taps have a stylish and modern design, with highly intelligent electronics, that offer a safeguard to misuse and vandalism. They provide the optimum in hygiene for the modern-day commercial washroom and comes fitted with 3.5lpm flow regulator as standard with a 5lpm flow regulator in the box, to support environmental building schemes such as BREEAM.
Features and Benefits
- Improved hygiene and reduce the transfer of infection
- Non touch – intuitive and easy to use. These non touch solutions are more hygienic and reduce the likelihood of spreading and receiving pathogens
- Water saving and energy efficient – the Vecta+ Sensor Tap contributes to building and environmental schemes, BREEAM
- Easy to install and maintain – chrome finished, easy to retrofit and swap out existing manual taps. External solenoid for easier servicing
- Mains and battery power options out of the box
- Safety shutoff – after 60 seconds of continuous water activation via sensor detection, the tap will automatically stop the flow of water to reduce the risk of flooding
- Smart shutoff – in the event of a power cut the device will automatically switch off the water flow to reduce the risk of a flooding event
- Support environmental building schemes
- Suitable for elderly or people with reduced mobility
- Optional extra – can added copper inlet pipes (tails)
3.5 Litres per minute: The Water Regulations require that the flow rate of a tap does not exceed 3.6 litres per minute where basins have no plug. The Vecta+ Sensor tap configured with a 3.5 litres per minute limit will ensure compliance in such applications. This model of flow restrictor is non-aerated and thus suitable for high risk applications such as medical facilities and care homes, where the risk to users of legionella and other water-carried respiratory contracted viruses/bacteria is high.
Aerators/Nozzles: Vecta+ Sensor infrared taps are supplied with interchangeable nozzle/aerators to allow the outlets to be configured to either a 3.5 or 5 litres per minute flow rate.
Dimensions
150mm W x 133mm H x 47mm D, Spray nozzle height above basin surface 111mm, Spray nozzle projection from tap body 83mm
Mounting requirements
Any horizontal surface up to 40mm in thickness, requires a hole of 28-32mm in diameter
Water supply
0.5 to 6 bar operating pressure
Power requirements
6V DC from 4 x alkaline AA (LR6) batteries or 6V DC regulated from mains adaptor (1A fused spur required)
Battery life
2 years in normal conditions with recommended batteries (a single red flashing of the LED indicates that the batteries are low and need to be replaced)
Electronic specification - power transformer
100-250v AC 50/60Hz 0.2A MAX
Electronic specification - Control Box Supply
6V DC 1A MAX (batteries or power transformer)
Ambient temperature range
Operating: 0 to 40⁰C
The flow of water from the taps is turned on when the user presents their hands to the infrared sensor which is located on the lower body of the Vecta+ Sensor Tap.
The infrared tap sends out an infrared LED bean (invisible to the human eye). When something interrupts this infrared beam, for example the user’s hand, the infrared light is bounced back to the receiver in the taps, which switches on the solenoid valve, to allow the water to flow.
No contact is required. The sensor automatically activates the externally-sited solenoid valve. When the user’s hands are moved away the flow of water stops after a 2 second delay.
