EasyflushEVO

Sensor activated siphon WC dual flush valve that is easy to install in a retrofit or new build installation.

Price(s) From
£ 264.00
Price (incl. VAT)

EasyflushEVO

Sensor activated siphon WC dual flush valve that is easy to install in a retrofit or new build installation.

Price(s) From
£ 264.00
Price (incl. VAT)

Choose Flush valve or flushing cistern

Flush valve or flushing cistern
Flush valve or flushing cistern

Choose Choose outlet size

Choose outlet size
Choose outlet size
Choose outlet size

Quantity

Your Selection

SKU -
Total Cost £ 0.00
Description

Specs

Product Information

The EasyflushEVO is our latest sensor-activated WC dual flush valve that is easy to install, as a retrofit or new build installation.

EasyflushEVO has been specifically designed to save water and be sustainable. There is no flush seal below the water line, so unlike traditional WC flush drop valves it will not leak due to debris, scale, or degradation of the seal.

The unique, patented design, means that no other sensor product offers the same level of confidence by reducing flush volumes via a sensor, or addresses the challenges of leaking loos, in the same way.

Manufactured to high standards, the stylish and rugged sensor plate is made from stainless steel and has the options for mains or battery power, out of the box as standard.

Features and benefits

  • Water saving and sustainable – patented siphon WC dual flushing valve. Designed with no flush seal below the water line
  • Save up to 78,475 litres of water per year. Product payback in as little as 8 months
  • Hygienic non-touch – The non-touch solution is more hygienic and reduces the likelihood of cross-contaminating pathogens
  • Intuitive user interface – Assists the user with flush activation for part or full flushing and feedback for cistern refilling
  • Easy to install and maintain – Ideal for retrofit or new build. Height adjustable filling valve to suit most cisterns (60mm height adjustment)
  • Mains and battery power options out of the box
  • No dependence on water pressure – EasyflushEVO flushing valve
  • Protects against limescale – self-cleaning flushing mechanism
  • Programmable flush volumes
  • Manual flush override – option available
  • Support environmental building schemes
  • Ease of use for elderly or people with reduced dexterity
  • UK Manufacturer
  • Extended warranty – 3 years



Dimensions - EVO 1.5 and EVO 2
20mm W x 240-300mm H x 101mm D.
Dimensions - EVO CISTERN
Cistern: 446mm W x 263mm H x 174mm D
Water supply - EVO 1.5 and EVO 2
EasyflushEVO flushing valve operation is not dependent on water supply pressure.
Water supply - EVO CISTERN
Filling valve: 0.1bar minimum and 10bar maximum water pressure
Pipe fitting
EVO 1.5: 1.5" outlet. EVO 2: 2" outlet. EVO CISTERN: 1.5" flush pipe outlet
Sensor range
Wave mode: ~18cm, Walkaway mode: ~65cm (~9cm for hand activation)
Power requirements
6V DC from 4 x alkaline AA (LR6) batteries or 6V DC regulated from mains adaptor (1A fused spur required)
Mains power supply
100-250v AC 50/60Hz 1A MAX
Normal battery life
27,000 activations
Rated ambient temperature range
Operating 0 to 40°C
  1. Wave mode (default): The flush is activated when an object (hand) is moved within range of the sensor. Walkaway mode: The flush is activated when the occupancy sensor detects the user has left the WC cubicle.
  2. Servo motor activated drives the servo arm downwards
  3. Activation shaft pushes plunger down
  4. The spill over level drops below the water line initiating a siphon and emptying the cistern
  5. Full flush volume is set by the water level and part flush is set by an electronic timer
  6. Once flush is complete, timer activates servo to return to original rest position

Here is a selection of documents, designed to ease specification and installation:

Warranty Cover

Parts only warranty (no labour) for equipment purchased in the United Kingdom, Ireland, Isle of Man and the Channel Islands. Components of the unit which are proven to be faulty or defective in manufacture will be exchanged or repaired.

Warranty Period

1 Year from Date of Manufacture

Extended Warranty Period (available on Registration)

3 Years from Date of Installation



Extended Warranty Terms

To register and qualify for Extended Warranty cover, the Cistermiser product must be correctly installed with the Commissioning Checklist fully completed as itemised in the Installation Guide (included with the product), to demonstrate compliance with the product installation instructions.

Each Commissioning Checklist activity should be dated and additional warranty details provided to enable registration: product serial number, installation date, installation site address and the installer’s name and contact details.

Extended Warranty can be registered online (via the Warranty section of this website) or by completing and returning the Commissioning Checklist from the Installation Guide (included with the product) to this address: Cistermiser Ltd, Unit 1, Woodley Park Estate, 59-69 Reading Road, Woodley, Berkshire RG5 3AN.



Product FAQs

We’re here to Help!

Q
Can I check what kind of indicators I should see for normal sensor function after user activation?
A

EasyflushEVO Wave and Walkaway mode user activation:

  • 1 green LEDs single flash one per second = part flush
  • 2 green LEDs single flash one per second = full flush
  • Alternating 3 green LEDs rising = re-flush has been requested
Q
I have completed the installation but there seems to be no water entering the cistern. What can I do?
A

Things to check:

  • No obvious indicator.

Solution: Ensure that the water supply is connected and the fill valve is operating correctly. Check filters for blockages.

  • The sensor may be covered.

Solution: Anti vandal mode has been triggered. The object/debris needs to be removed from the sensor and the valve will resume normal functionality.

Q
I have completed the installation but the flush valve does not seem to be working at all. How can I fix this?
A

Things to check:

  • Is the sensor light not flashing when a hand is placed in front of it?

Solution: Ensure the power supply is connected. If the mains power is being used through the mains adaptor, then check that the mains adaptor is working by reverting to the battery pack.  Remove the mains adaptor when using batteries.



  • Is the sensor light flashing a single top red LED slowly, or not at all when a hand is placed in front of it?

Solution: There is likely to be low battery power. Change the batteries.  If the mains power is being used through the mains adaptor, then check wiring and contact Cistermiser on 0118 969 1611 for advice.

  • Flush volume is too low.

Solution: Ensure full flush time is correct (default 3 seconds), so all water is flushed from the cistern. Refer to the EasyflushEVO Installation Guide, Valve set up (section 4).

Adjust flush valve and fill valve height to change the full flush volume.

  • No obvious indicator, Sensor LEDs are OK.

Solution: Check fill valve and flush valve are aligned with the water level. Ensure cistern is level. Check manual activation lever to down (neutral position).

Q
I have completed the installation but there is a continuous water flow into the pan from the cistern. What can I do?
A

Things to check:

  • No obvious indicator.

Solution: Water flowing through the overflow; ensure that the water entering the cistern is being shut off by adjusting the float accordingly. If the float is set too high, water will continuously flow into the cistern and out of the overflow.

Q
The toilet flushes when in use. What could be causing this?
A

Things to check:

  • Working as normal otherwise.

Solution: Ensure that the sensor is mounted in the correct position. Refer to the EasyflushEVO Installation Guide, Sensor positioning (section 5).

Ensure the sensor range is also correctly configured. Refer to the EasyflushEVO Installation Guide, Advanced setting guide (section 9).



Q
I have completed the installation but still experiencing issues. What can I do?
A

Things to check:

  • Does the sensor display flashing double red bottom LEDs?

Solution: This could be due to faulty wiring so check the wiring carefully. Alternatively, this could be due to a faulty solenoid. If so please call Cistermiser on 0118 969 1611 for advice.

  • Does the sensor display a flashing single red top LEDred flash once every second?

Solution: Either there is low battery power. Change batteries. If the unit is being operated by mains power, then check wiring and then contact Cistermiser.

  • Does the sensor display flashing triple red LEDs?

Solution: Sensor is either covered or heavily scratched. Uncover sensor or polish out scratches on sensor.

  • Does the sensor display flashing double red top LEDs?

Solution: This could be due to a servo motor obstruction. If so please call Cistermiser on 0118 969 1611 for advice.

Not found the answers to what you’re looking for? We’re here to help!

Whether you need help with product support or installation advice, our dedicated support staff are on hand today.
